Description
SPECIFICATIONS
| Model | IM100S | |||
| Feed Size | ≤15mm | |||
| Final Fineness | About 5 µm (Depending on the nature of the sample and grinding environment) | |||
| Feeding Quantity | 6×100mL | |||
| Display | LCD touch | |||
| Setting Grinding time | 1s-99h59min59s Continuously adjustable |
|||
| Intermittent Time setting | 1s-99min59s | |||
| Stop Time setting | 1s-99min59s | |||
| Setting Vibrational frequency | 1Hz-35Hz（60rpm-2100rpm） | |||
| Grinding Environment range | Dry,Wet,Low temperature grinding in Liquid nitrogen | |||
| Grinding Jar volume | 50ml,35ml,25ml,10ml,5ml | |||
| Grinding Jar material | Chrome steel,Stainless steel, Zirconia,Tungsten carbide,PTFE,Agate |
|||
| Adapter | 5ml×4 holes (Stainless steel), 5ml×6 holes, 5ml×12 holes, 2ml×10 holes, 2ml×24 holes, 2ml×48 holes, 1.2ml×96holes, | |||
| Adapter Material | PTFE,Stainless steel,Aluminum | |||
| Grinding Ball diameter | 0.1-1.5mm,2mm,3mm,5mm,7mm, 10mm,15mm,20mm,25mm,30mm |
|||
| Tool For opening | Suitable for 5ml-50ml grinding jar | |||
| Grinding Platform | 2 | |||
| Load Display | Yes | |||
| Automatic center positioning device | Yes | |||
| Automatic Storage parameter combination | 10 groups | |||
| Cycles | 1-20 times | |||
| Dimension (mm) | 384×267×461 | |||
| Net Weight | Approx. 30Kg | |||
| Electrical Parameters | 220V/240W | |||
