| Specifications |
IHCM100-Pro |
IHM100-Pro |
| Functions |
Heating,cooling&mixing |
Heating&mixing |
| Temperature range [℃] |
Below room temp 15- 100 |
Room temp-100 |
| Temperature Setting range [℃] |
0-100 |
15-100 |
| Temperature control accuracy@20-45 [℃] |
±0.5 |
±0.5 |
| Temperature uniformity@20-45 [℃] |
±0.5 |
±0.5 |
| Power [W] |
200 |
200 |
| Time setting range |
0min~99h30min |
0min~99h30min |
| Max Heating speed |
5.5℃/min |
5.5℃/min |
| Max Cooling speed |
5℃/min(100℃-room temp) 0.5℃/min(below room temp) |
– |
| Mixing speed [rpm] |
200-1500 |
200-1500 |
| Mixing orbit [mm] |
3 |
3 |
| Display |
TFT |
TFT |
| Program |
9 |
9 |
| Overheating protection [℃] |
150 |
150 |
| Voltage,Frequency |
110/220V，50/60HZ |
110/220V，50/60HZ |
| Dimension [mm] |
200x235X120 |
200x235X120 |
| Weight [kg] |
7.3 |
7.3 |
| Operating temperature [℃] |
10-40 |
10-40 |
| Operating humidity [% RH] |
＜80 |
＜80 |
