| Model |
IMR-200 |
IMR-200c |
IMR-200n |
| Standard Filter（nm） |
405，450，492，630 |
| Wavelength Range（nm） |
400-800 |
| Operation |
Touch screen、Connect to PC |
Touch screen、Connect to PC |
Only connect to PC |
| Reading Range（A） |
0.000~4.000 |
0.000~4.000 |
0.000~4.000 |
| Measurement Channel |
8 channels |
| Reference Channel |
1 channels |
No |
No |
| Microcontroller |
Intel CPU |
ARM core CPU |
PIC microcontroller |
| Test Item |
More than 500 |
More than 500 |
Single machine without storage function, connected to PC can store more than 500 |
| Test Data |
More than 100,000 plates（96 holes） |
2000 plates（96 holes） |
More than 100,000 plates（96 holes）and need to connect to PC |
| Display |
Touch screen , 10.4″color LED display |
Touch screen, 7”high resolution LCD display |
No |
| Communication Interface and Report Printing |
USB port、RS232 serial port、DVI port、LAN port、VGA port、Built-in thermal printer |
USB port、RS232 serial port、Parallel port printer interface、Built-in thermal printer |
USB port |
| LED light |
Optional |
Optional |
Standard |
| Pituitary Perfusion |
Optional |
Optional |
Optional |
